High quality 50mm 24v 48V 50 x 50 x 10 mm waterproof cooling fan
with CE ROHS certifications
Function: FG RD PWM IP58 IP68
Frame and Impeller: Plastic (94V-0),PBT
Bearing Type: Sleeve bearing&Ball bearing
Function Range:FG RD PWM IP58 IP68
Leadwire: Red Wire Positive(+),Black Wire Negative(-)
Operating Voltage: 5V 12V 24V
Tempetature Range: –20℃ to +70℃
Motor: Impedance Protected and Reverse Polarity Protected
Specification
| Rated Voltage | Operating Voltage | Input Current | Input Power | Speed | Max Air Flow | Max Static Pressure | Noise | Weight |
|
| VDC | VDC | Amp | Watt | RPM | CFM | m3/min | Inch-H2O | pa | dB-A | g |
| 5 | 3.5-5.5 | 0.25 | 1.25 | 5500 | 10.83 | 0.31 | 0.13 | 33.15 | 34.00 | 20.00 |
| 5 | 3.5-5.5 | 0.21 | 1.05 | 5000 | 9.91 | 0.28 | 0.11 | 26.77 | 31.00 | 20.00 |
| 5 | 3.5-5.5 | 0.18 | 0.90 | 4500 | 9.26 | 0.26 | 0.10 | 23.93 | 28.00 | 20.00 |
| 5 | 3.5-5.5 | 0.15 | 0.75 | 4000 | 7.64 | 0.22 | 0.07 | 17.55 | 26.00 | 20.00 |
| 12 | 7.0-13.8 | 0.16 | 1.92 | 6000 | 12.02 | 0.34 | 0.16 | 39.32 | 37.00 | 20.00 |
| 12 | 7.0-13.8 | 0.14 | 1.68 | 5500 | 10.83 | 0.31 | 0.13 | 33.15 | 34.00 | 20.00 |
| 12 | 7.0-13.8 | 0.12 | 1.44 | 5000 | 9.91 | 0.28 | 0.11 | 26.77 | 31.00 | 20.00 |
| 12 | 7.0-13.8 | 0.10 | 1.20 | 4500 | 9.26 | 0.26 | 0.10 | 23.93 | 28.00 | 20.00 |
| 12 | 7.0-13.8 | 0.08 | 0.96 | 4000 | 7.64 | 0.22 | 0.07 | 17.55 | 26.00 | 20.00 |
| 24 | 14.0-27.6 | 0.12 | 2.88 | 6000 | 12.02 | 0.34 | 0.16 | 39.32 | 37.00 | 20.00 |
| 24 | 14.0-27.6 | 0.10 | 2.40 | 5500 | 10.83 | 0.31 | 0.13 | 33.15 | 34.00 | 20.00 |
| 24 | 14.0-27.6 | 0.08 | 1.92 | 5000 | 9.91 | 0.28 | 0.11 | 26.77 | 31.00 | 20.00 |
| 24 | 14.0-27.6 | 0.06 | 1.44 | 4500 | 9.26 | 0.26 | 0.10 | 23.93 | 28.00 | 20.00 |
| 24 | 14.0-27.6 | 0.04 | 0.96 | 4000 | 7.64 | 0.22 | 0.07 | 17.55 | 26.00 | 20.00 |
Market
We have an experienced and professional team of manufacturing fan. Our product exported to many countries. Our
main markets are south Asia,south America, Europe.
“Concentrate on the sevice of customer” is our purpose. We welcome
customers, bussiness associations and friends from all part of
world.
We hope to meet your cooperation sincerely.
Our company
ShenZhen Topfan China is a professional manufaturer with 11 years experience Which produces AC fan, DC fan, brushless fan,
blower fan and EC fan. Our main markets are south Asia,south America, Europe.
“Concentrate on the sevice of customer” is our purpose.
Packing:
Carton box or according to customers demand
Shipment:
1. FOB Shenzhen or HongKong (mass production)
2. DHL,UPS,FEDEX,TNT or any other international express (sample or
small quantity)
Delivery Time:
Generally, 500~1000pcs 10 days after confirming the PI
Payment:
T/T and paypal
1. The payment for the high value sample will be charged.
2. The payment for the low value sample is free, but the freight
should be paid by you.
AFQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for but not free
Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is
15-20 days if the goods are not in stock, it is according to
quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50%
T/T in advance ,balance before shippment.
