    Computer 5V / 12V / 24V 2010 DC Brushless Cooling Fan Speed Control

    Ask Lasest Price
    Brand Name : Topfan / OEM
    Model Number : MX2010AB(S)H5
    Certification : CE ROHS UL
    Price : USD + 1 / 5 + Piece
    Payment Terms : T/T, Western Union
    Supply Ability : 100000 + Piece + A Week
    Delivery Time : 7 / 10 Working Days
    • Product Details
    • Company Profile

    Computer 5V / 12V / 24V 2010 DC Brushless Cooling Fan Speed Control

    Computer 5V / 12V / 24V 2010 DC Brushless Cooling Fan Speed Control


    General Specifications :


    Frame

    plastic ( UL94v - 0 )

    Impeller

    plastic ( UL94v - 0 )

    Bearing type

    Sleeve Bearing and Dual Ball Bearing

    Leadwire

    UL1571AWG # 28 or Equivalent ( + ) : Red ( - ) : Black

    Motor

    Impedance Protected and Reverse Polarity Protected

    Voltage

    5V , 12V , 24V

    Certification

    ISO9000 , UL , CE , RoHS , TUV


    Expected Life :


    1 . Ball Bearing 50,000 hours ( 40°c )

    2 . Sleeve Bearing 30 , 000 hours ( 40°c )


    Allowable Ambient Temperature Range

    1 . - 10°c ~ + 70°c ( Operating )

    2 . - 40°c ~ + 70°c ( Storage )

    3 . ( non - condensing environment )


    Specification :


    Model

    Bearing Type

    Rated Voltage

    Operating Voltage

    Input Current

    Input Power

    Speed

    Max Air Flow

    Max Static Pressure

    Noise

    Weight

    MX2010AB(S)H5

    B.S

    5

    2.8-5.5

    0.13

    0.65

    15000

    1.25

    0.04

    0.14

    35.01

    27.00

    5.00

    MX2010AB(S)M5

    B.S

    5

    2.8-5.5

    0.10

    0.50

    10000

    0.73

    0.02

    0.05

    11.77

    22.00

    5.00

    MX2010AB(S)L5

    B.S

    5

    2.8-5.5

    0.07

    0.35

    8000

    0.42

    0.01

    0.04

    8.73

    21.00

    5.00

    MX2010AB(S)H1

    B.S

    12

    7.0-13.8

    0.07

    0.84

    20000

    1.70

    0.05

    0.24

    60.90

    30.00

    5.00

    MX2010AB(S)M1

    B.S

    12

    7.0-13.8

    0.50

    0.60

    15000

    1.25

    0.04

    0.14

    35.01

    27.00

    5.00

    MX2010AB(S)L1

    B.S

    12

    7.0-13.8

    0.03

    0.36

    10000

    0.73

    0.02

    0.05

    11.77

    22.00

    5.00
